Automatic Servo Motor Universal M10 M12 M16 M20 M24 M36 Electric Tapping Machine with Touch Screen

Automatic Servo Motor Universal M10 M12 M16 M20 M24 M36 Electric Tapping Machine with Touch Screen
MODEL:
M3-M10
M3-M16
M6-M24
M3-M12
M3-M20
M6-M30
M6-M36
Availability:
Quantity:
Inquire Add to Basket

sharethis sharing button

  • M10 M12 M16 M20 M24 M36

  • ZH

  • 84597000

  • Alloy Steel

  • elctronic

  • Automatic Servo Motor Universal M10 M12 M16 M20 M24 M36 Electric Tapping Machine with Touch Screen

  • ZH

Automatic Servo Motor Universal M10 M12 M16 M20 M24 M36 Electric Tapping Machine with Touch Screen


Product features::


1.This machine adopts servo drive control with intelligent torque protection, which gets rid of the limitations of traditional lathes, drilling machines or manual tapping.
2.Continuously variable speed, manual, automatic, linkage three working modes, you can choose.
3.The serpentine plastic wire and conduit protect the circuit and do not affect the rotation of the fuselage.

4.The safety torque clamp ensures less damage to the tap and high tapping accuracy.


Touch Screen Servo Drive Tapping Machine
Tapping range
Working radius
Drive type
Power(KW)
Max. speed (r/min)
Voltage
Tapping direction
Control panel
Tapping collet
M3-10
1.25m
Servo drive
0.6
0-1000
220V
Universal
Touch Screen
M3-10
M3-12
1.25m
Servo drive
0.6
0-625
220V
Universal
Touch Screen
M3-12
M3-16
1.25m
Servo drive
0.6
0-312
220V
Universal
Touch Screen
M3-16
M3-16
1.25m
Servo drive
2
0-625
220V
Universal
Touch Screen
M3-16
M3-20
1.25m
Servo drive
0.6
0-200
220V
Universal
Touch Screen
M3-20
M3-20
1.25m
Servo drive
2
0-416
220V
Universal
Touch Screen
M3-20
M6-24
1.25m
Servo drive
2
0-200
220V
Universal
Touch Screen
M6-24
M6-30
1.25m
Servo drive
2
0-156
220V
Universal
Touch Screen
M6-30
M6-36
1.25m
Servo drive
2
0-100
220V
Universal
Touch Screen
M6-36



6
