[Product Overview]

The American Type Drill Press Vise is the standard workholding solution for pillar drills, radial arm drills, and light milling machines. Attempting to hold a workpiece by hand while drilling is extremely dangerous; if the drill bit catches, it can spin the part with immense force. This vise provides a rigid, secure grip on your material, ensuring operator safety while drastically improving the accuracy of drilling, reaming, and tapping operations. Its "American Type" designation refers to its robust, wide-stance design and elongated side slots, which are highly favored in North American and international workshops for their reliability and ease of use.

[Key Features & Advantages]

• High-Strength Cast Iron Body: Cast from premium, heavy-duty iron to provide exceptional rigidity, prevent distortion under high clamping pressure, and dampen machining vibrations.

• Precision Machined Surfaces: The base and sliding surfaces are precision milled or ground flat. This ensures the vise sits perfectly square on the drill press table, guaranteeing holes are drilled perfectly perpendicular to the workpiece.

• Hardened Steel Jaws with V-Grooves: The replaceable jaw plates are made of hardened steel for long life. They feature horizontal and vertical V-grooves, making it easy to securely clamp round stock, tubing, or irregular shapes.

• Elongated Mounting Slots: Designed with wide, continuous slots along the sides of the base, allowing for rapid and flexible mounting to almost any T-slot machine table configuration.

• Smooth Acme Lead Screw: Equipped with a precision-machined Acme threaded lead screw and a knurled or drop-forged handle, providing smooth jaw movement and powerful clamping force with minimal effort.

[Why Partner with Pingyuan Zhenghao Machinery?]

• Direct Manufacturer Savings: Bypass trading companies and source essential workshop workholding tools directly from our factory for highly competitive wholesale pricing.

• Comprehensive Size Range: We manufacture these vises in a wide variety of jaw widths (commonly 3", 4", 5", 6", and 8") to accommodate everything from small benchtop drill presses to massive radial arm machines.

• Strict Quality Control: Every vise is inspected for jaw parallelism, smooth screw operation, and base flatness before it leaves our facility.

• OEM & Customization: We offer custom paint colors (e.g., classic machine gray, blue, or black) and custom branding/packaging for retail distributors and catalog companies.

Frequently Asked Questions (FAQ) - Selection Guide

Q1: What makes this an "American Type" vise compared to others?

A: The "American Type" generally refers to a specific, time-tested design characterized by a wider, lower-profile body, a very sturdy fixed jaw, and long, open mounting slots on the sides. It prioritizes sheer clamping strength and durability over complex features, making it a staple in heavy-duty environments.

Q2: Can this vise hold round pipes or shafts?

A: Yes. The hardened steel jaw plates are machined with built-in V-grooves (typically both horizontal and vertical). These grooves cradle round stock securely, preventing it from rolling or slipping while being drilled.

Q3: How do I secure the vise to my drill press table?

A: You use standard T-slot bolts, washers, and nuts. Drop the T-bolts into the slots on your drill press table, slide the vise so its elongated side slots align with the bolts, and tighten the nuts down securely.

Q4: Can I use this vise on a milling machine?

A: While it is exceptionally strong for drilling, reaming, and tapping, a drill press vise is generally not recommended for heavy milling operations. Milling generates strong lateral (side-to-side) forces that require a dedicated, higher-precision milling vise (like a GT precision vise or an Anglock style vise) to prevent the workpiece from shifting.

Secure your workpieces safely and accurately with our rugged American Type Drill Vises.

Contact our sales team today for a complete catalog and bulk pricing.
