| Size: | |
|---|---|
BT40 HSK63 MT3 SK40
ZHORTMA
8466100000
Alloy Steel
56-58HRC
Machine tools collet chuck tool holder clamping accessories
Tapping chuck
0.005mm
milling machine
Silver
0.005mm
G2.5 25000rpm
TER Tapping Chuck BT40 HSK63 MT3 D25 Tapping Tool Holder
ZH
BT30 BT40 BT50 WF12 WF24 WF33 Tapping Tool Holder M2-M30 ISO JIS DIN Tap Chuck Collet Tool Holder
Material: 20CrMnTi
Taper tolerance:<AT3
Carbon depth: 0.8mm±0.2mm
Max. Run out: <0.005mm
Package and shipment
Packing: 1pcs/plastic bag, plastic box inside ,carton box outside can also packing as your request.
Shipping: 3-7days after payment, by international express or as your request.
Company Profile
Pingyuan Zhenghao Machinery CO, LTD was found in 1998, professional produced GT precision modular vise, quick change tool post, tool holder, collets, end mills. It is a professional manufacturer of CNC lathe accessories in china. We have export experience for more than 10 years , Our productions export to more than 20 countries and regions.
Our company adheres to the principles of "quality first, customers supreme and reputation fundamental". we sincerely welcome foreign customers to visit us .
Time spent changing tools is time your machine isn't making money. The BT Series Tapping Holder with WF Interface is the global standard for rapid, reliable tap changes in high-production CNC environments. The holder body is precision-engineered to mate perfectly with your machine's spindle, while the front end features a quick-release ball-bearing locking mechanism. This allows the WF series tap collets to snap in and out instantly. Whether you are performing high-speed rigid tapping or require holders with built-in length compensation, the WF system delivers unmatched versatility and speed.
Universal WF Quick-Change System: Fully compatible with industry-standard WF12, WF24, and WF33 (often interchangeable with Bilz-style) tap collets. The quick-release collar enables tool-free tap changes in under 3 seconds.
Comprehensive Machining Range:
WF12 Interface: Ideal for small to medium taps, covering M2 to M14/M16.
WF24 Interface: Designed for standard to heavy-duty tapping, covering M5 up to M24/M30.
WF33 Interface: Engineered for large diameter threading, covering M14 up to M36.
Global Tap Compatibility: We supply WF collets specifically machined to fit the exact shank and square drive dimensions of ISO, JIS, and DIN standard taps, ensuring a 100% positive, slip-free drive.
High-Precision BT Shank: The MAS 403 BT shanks (BT30, BT40, BT50) are manufactured from premium 20CrMnTi alloy steel, case-hardened to HRC 56-58, and precision-ground to AT3 taper accuracy for maximum spindle contact and minimal runout.
Rigid or Floating Options: The main tool holder bodies are available in solid (rigid) designs for modern synchronized CNC machines, or with built-in tension/compression (axial float) for older machines to prevent tap breakage.
Direct Manufacturer Savings: Source your complete quick-change tapping systems directly from our factory, bypassing middlemen for highly competitive wholesale costs.
Complete Tooling Packages: We supply the BT holders as well as a full range of matching WF collets (both rigid and torque-control/overload protection types).
Custom Solutions: Need coolant-through capabilities or extended gauge lengths? Our engineering team can provide customized holders to meet your specific application needs.
Strict Quality Control: Every holder undergoes rigorous testing for taper accuracy, concentricity, and quick-change mechanism smoothness before shipment to ensure flawless performance.
Q1: Are WF collets interchangeable with other brands?
A:Yes, in most cases. The WF12, WF24, and WF33 interfaces are based on a widely adopted international standard (often referred to as the Bilz standard). Our holders will generally accept standard quick-change collets from other major tooling brands that use this same interface size.
Q2: Should I choose a Rigid holder or a Tension/Compression holder?
A: If your CNC machine has "Rigid Tapping" (synchronized spindle and Z-axis feed), you can use a Rigid BT-WF holder. If your machine is older and lacks this feature, or if you are tapping very tough materials and want to improve thread finish and tap life, you should choose a BT-WF holder with Tension & Compression (Axial Float) to absorb synchronization errors.
Q3: Do the WF collets have overload protection?
A: The WF interface refers to the quick-change connection size. The collets themselves come in two types: Rigid Collets (solid drive) and Torque-Control Collets (with a built-in slip clutch). If you are tapping blind holes and want to prevent tap breakage, you should specify Torque-Control WF collets when ordering.
Q4: How do I ensure the collet fits my tap perfectly?
A: Taps manufactured to JIS, DIN, and ISO standards have different shank diameters and driving square dimensions for the exact same thread size. You must ensure that the WF collet you select specifically matches the standard (JIS, DIN, or ISO) of the tap you are using. Please provide your tap standard and sizes when requesting a quote, and we will match the correct collets for you.
Speed up your setups and secure your tapping operations with our BT Tapping Holders and WF Quick-Change Collets.
Contact our sales engineering team today for a complete catalog, collet compatibility charts, and bulk pricing.
